Descripción
Descripción
- Modular chassis switch Layer 3
- Size of 9U
- 6 Free slots for cards
- Up to 288 Gigabit Rj45 Ports
- Up to 288 Gigabit SFP Ports
- Up to 96 SFP+ ports
- Switching capacity up to 1.92Tbps
- Forwarding rate up to 1440Mbps
- MAC table of 32K
- Up to 1900 ACL rules
- Modular power supplies not included
Especificaciones
| Size | 9 Rack units |
| Expansion Slot | 6 card slot RG-M7000 |
| Management Level | L3 |
| Interfaces | Up to 288 RJ45 ports 10/100/1000 Mbps Up to 288 ports SFP10/100/1000 Mbps Up to 96 SFP+ 10Gigabit ports *The purchase of one or more RG-M7000 cards is required and, depending on the cards chosen, the interfaces may vary |
| Switching Capacity | 1.92Tbps |
| MAC Table | Up to 32K |
| ACL | Up to 1900 rules |
| Reshipment Rate | 1440Mbps |
| VLAN | Up to 4096 Voice VLAN Port-Based VLAN MAC-Based VLAN IP-Based VLAN |
| Redundancy control | Spanning Tree (STP, RTSP) RLDP |
| Network Protocols and Technologies | LLDP/LLDP-MED IGMP Snooping v1/v2/v3 CPU Protect Policy Energy Efficient Ethernet ACL Jumbo Frame 9216 SNMP 802.1X RIP OSPF DHCP Server DHCP Snooping |
| Cluster Technology | Virtual Cluster Switching |
| Management Protocols | Web/Cloud/APP |
| Power | 4 Redundant power supply slot. Compatible: RG-PA600I-FS (AC 600W)) (Power supply not included) |
| Operating temperature | 0° C - 50° C |
| Cooling | 1 Slot for ventilation module. Compatible: NBS7006-FAN |
| Weight | 30 Kg (With packaging) |
| Dimensions | 442 mm x 410 mm x 396 mm 9U |
