Camera
|
|
Pixel
|
2 MP
|
|
Image Sensor
|
2 MP CMOS
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s
|
|
Min. Illumination
|
0.001 lux@F1.6 (Color, 30 IRE)
0.0001 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>65 dB
|
|
Illumination Distance
|
IR: 40 m (131.23 ft)
Warm light: 40 m (131.23 ft)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
2 (IR light)
2 (Warm light)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm
3.6 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
2.8 mm: H: 108°; V: 58°; D: 127°
3.6 mm: H: 86°; V: 46°; D: 101°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 0.7 m (2.29 ft)
3.6 mm: 1.1 m (3.61 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
42.2 m (138.45 ft)
|
16.9 m
(55.45 ft)
|
8.4 m
(27.56 ft)
|
4.2 m
(13.78 ft)
|
|
3.6 mm
|
53.7 m (176.18 ft)
|
21.5 m
(70.54 ft)
|
10.7 m
(35.10 ft)
|
5.4 m
(17.72 ft)
|
|
Video
|
|
Video Frame Rate
|
CVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960 × 576H;
NTSC: 960 × 480H
|
|
Resolution
|
1080p (1920 × 1080); 960H (960 × 576/960 × 480)
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
BLC; HLC; WDR
|
|
WDR
|
130 dB
|
|
White Balance
|
Auto; Area white balance
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
3D NR
|
|
Smart Illumination
|
Yes
|
|
Mirror
|
Off/On
|
|
Privacy Masking
|
Off/On (8 areas, rectangle)
|
|
Illuminator
|
Smart IR&WL; WL Mode; IR Mode
|
|
Active Deterrence
|
|
Sound Warning
|
Audio1: alarm
Audio2: No parking here
Audio3: Private land no entry.
Audio4: Warning zone keep off
Audio5: Welcome
Volume: high/medium/low;
duration: 5 s–60 s; 110 dB
|
|
Red/Blue Light Warning
|
Flash: 5 s–60 s; frequency: high/medium/low
|
|
Certification
|
|
Certifications
|
CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14)
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Audio Input
|
One channel built-in MIC (-A)
|
|
Power
|
|
Power Supply
|
12 VDC ± 30% (It is recommended to use a power adapter to supply the power for one camera)
|
|
Power Consumption
|
Max 7.6 W (12 VDC, IR on)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
<95% (RH), non-condensing
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing Material
|
Metal front cover + plastic rear barrel + metal bracket
|
|
Product Dimensions
|
240.7 mm × Φ90.7 mm (9.48" × Φ3.57")
|
|
Packaging Dimensions
|
299 mm × 119 mm × 111 mm (11.77" × 4.69" × 4.37")
|
|
Net Weight
|
0.44 kg (0.97 lb)
|
|
Gross Weight
|
0.70 kg (1.54 lb)
|
|
Installation
|
Wall mount; ceiling mount; vertical pole mount
|
