Camera
|
|
Image Sensor
|
1/2.8" CMOS
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
Pixel
|
2MP
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100/000 s
|
|
S/N Ratio
|
> 65 dB
|
|
Min. Illumination
|
0.002 Lux/F1.6, 30 IRE, 0 Lux IR on
|
|
Illumination Distance
|
60 m (196.9 ft)
|
|
Illuminator On/Off Control
|
Auto; manual
|
|
Illuminator Number
|
2 (IR light)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed lens
|
|
Mount Type
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm; 6 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
2.8 mm: H: 107°; V: 56°; D: 127°
3.6 mm: H: 86°; V: 46°; D: 101°
6 mm: H: 54°; V: 29°; D: 63°
|
|
Iris Type
|
Fixed iris
|
|
Close Focus Distance
|
2.8 mm: 0.7 m (2.3 ft)
3.6 mm: 1.1 m (3.6 ft)
6 mm: 2.5 m (8.2 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
43.9 m
(144 ft)
|
17.5 m (57.4 ft)
|
8.8 m
(28.9 ft)
|
4.4 m
(14.4 ft)
|
|
3.6 mm
|
53.7 m (176.2 ft)
|
21.5 m (70.5 ft)
|
10.7 m (35.1 ft)
|
5.4 m
(17.7 ft)
|
|
6 mm
|
82.8 m (271.7 ft)
|
33.1 m (108.6 ft)
|
16.6 m (54.5 ft)
|
8.3 m
(27.2 ft)
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|
Video
|
|
Frame Rate
|
CVI:
PAL: 1080P@25 fps; NTSC: 1080P@30 fps;
AHD:
PAL: 1080P@25 fps; NTSC: 1080P@30 fps;
TVI:
PAL: 1080P@25 fps; NTSC: 1080P@30 fps;
CVBS:
PAL: 960 × 576H; NTSC: 960 × 480H
|
|
Resolution
|
1080P (1920 × 1080); 960H (960 × 576/960 × 480)
|
|
Day/Night
|
Auto switch by ICR
|
|
BLC
|
BLC/WDR/HLC
|
|
WDR
|
130 dB
|
|
White Balance
|
Auto; manual
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
3D NR
|
|
Smart IR
|
Yes
|
|
Mirror
|
Off/On
|
|
Privacy Masking
|
Off/On (8 area, rectangle)
|
|
Certifications
|
|
Certifications
|
CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Audio Input
|
One channel built-in mic (-A)
|
|
Power
|
|
Power Supply
|
12V ±30% DC
|
|
Power Consumption
|
Max 5.1 W (12V DC, IR on)
|
|
Environment
|
|
Operating Temperature
|
–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation)
|
|
Storage Temperature
|
–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation)
|
|
Structure
|
|
Casing
|
Metal front cover+plastic main body+metal bracket
|
|
Camera Dimensions
|
198.4 mm × 80.2 mm × 76.2 mm (7.81" × 3.16" × 3.00")
|
|
Net Weight
|
0.3 kg (0.66 lb)
|
|
Gross Weight
|
0.45 kg (0.99 lb)
|
