Descripción
Patch cords general characteristics |
|
| Temperature range | - 20°C to +60°C(OM1,OM2,OM3,OM4,OS2) - 5°C to +60°C (OM4A) |
| Mating cycles | > 500 cycles |
| Colour of sheath | Yellow (OM1, OM2, OS2) | Aqua (OM3 OM4A) | Erica Violet (OM4), |
| Fiber version | 3mm (OM3, OM4,OM4A,OS2) | 3mm (ST & SC) or 2mm (LC,MU) (OM1, OM2) |
| Colour of boots | Black & Red (OM1, OM2) | Black & Red (ST & SC) White(LC)(OM3, OM4,OM4A) | Green & Black (OS2APC) | Blue & Black (OS2) |
| Return Loss | > 20dB (OM1,OM2,OM3,OM4) | > 40dB (OS2) |
| Insertion Loss (Attenuation) | < 0.3 dB(OM1,OM2,OM3,OM4,OS2) | < 0.25dB (OM4A) |
Connectors technical characteristics |
|
| Types | ST, SC, LC, FC, MU UPC (other on request) |
| Material of ferrule | ZrO2 (Zirconia / Ceramic) |
| Connector surface | Convex |
| Fiber’s connection | Epoxy |
| Material of body | Metal (ST, FC) or composite (SC, LC, MU) |
| Ferrule drilling | 125/126µm (OS2) | 127/128µm (OM1,OM2,OM3,OM4, OM4A) |
Optical cable mechanical properties |
|
| Weight | 15 kg/km |
| Temperature range | -20°C to +60°C (-5°C to +70°C OM4A) |
| Bending radius | 40 mm |
| Tensile strength | 250N (long term) – 450N (short term) |
| Crush resistance | 1000N/dm (OM1,OM2,OM3,OM4,OS2) | 2000N/dm (OM4A) |
